2 Player 24" Bartop Arcade Cabinet Flat Pack Kit - Black

2 Player 24" Bartop Arcade Cabinet Flat Pack Kit - Black

SKU:
EAN:
Regular price £226.00 GBP
Regular price Sale price £226.00 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.
  • Free Delivery
  • Manufactured to order with approx. 10 working days lead time

Low stock

Control Panel Plexi

Features

  • Features a removable control panel for easy access to joysticks/buttons/wiring
  • Adjustable MDF VESA mount bracket and bolts included
  • Supplied with 4mm plexi set for monitor and marquee area
  • All fixings and instruction sheet included for self assembly
  • Joystick bolts included
  • Suitable for various projects including JAMMA and Raspberry Pi
  • T-Molding slots pre-cut
  • Compatible with 24" monitors
  • Most popular joysticks will fit, including Sanwa, Seimitsu, SuzoHapp, IL, Zippyy and illuminated joysticks
  • Most popular arcade buttons will fit, including Sanwa, Seimitsu, SuzoHapp, IL, Gold Leaf and illuminated
  • Black finish
  • Supplied in flat pack form for self assembly

Specifications

Carcass Material: 18mm Black MDF
Acrylic Screen Cover: Clear Solid Polycarbonate Sheet
461mm (H) x 599mm (W) x 4 (D) mm
Acrylic Marquee: Clear Solid Polycarbonate Sheet
112 (H) x 299 (W) x 4 (D) mm
Number of Players: 2 Player
Assembled Dimensions: 740 (H) x 625 (W) x 496 (D) mm
Monitor Compatibility: Compatible with VESA 75mm and 100mm square hole pattern.
Monitor / Screen Compatibility: Compatible with up to a 24” monitor with the following maximum dimensions:
450 mm (H) – Maximum VIEWABLE height
585 mm (W) – Maximum OUTER width
90 mm (D) – Maximum OUTER depth
Joystick Compitability: Compatible with Zippyy, Sanwa, Seimitsu and others with SE mounting plates.
Button Compatibility: Compatible with 28mm and 30mm buttons, including Suzo Happ, Industrias Lorenzo Convex, Seimitsu, Samducksa and QanBa.
Number of Player Joystick and Button Holes: 2 x Joystick holes (1 x per person)
12 x Player Button holes (6 x per person)
4 x Action/Admin Button holes (2 x per person)
Speaker Compatibility: The speaker holes are designed to fit a speak with mounting holes 75mm apart or bigger.
T-Molding Compatibility: Compatible with 3/4” (19mm) T-Molding, that fits a 1/16” (1.58mm) slot. We recommend purchasing 17ft (5.2m) of T-Molding to complete the Arcade Kit.
Package Dimensions: 130 (H) x 800 (L) x 720 (W) mm
Package Weight: 22.1kg

View full details

Description

2 Player 24" Bartop Arcade Cabinet Flat Pack Kit - Black

The 24 Inch 2 player bartop arcade cabinet is manufactured from 18mm MDF and professionally cut on a CNC machine for perfect precision every time. This flat pack arcade cabinet kit features a 2 player layout, black finish and is compatible with 24" monitors. An adjustable wooden VESA mount and bolts are included in the box with each kit. The control panel is pre-drilled for a 2 player layout and the button holes are 30mm in diameter, so compatible with many of the popular brands on the market, including Sanwa, Seimitsu, IL, Suzo Happ, classic arcade buttons and more. The joystick holes are recessed, so most of the popular joysticks on the market will mount in this kit, including Zippyy, IL, SuzoHapp, Sanwa and Seimitsu. Each kit has been pre-slotted for t-molding. This 24 inch flat pack arcade cabinet kit comes supplied with an 4mm plexi set for monitor and marquee area, joystick bolts, instructions and also includes all fixings required for self assembly.

Pre-Drilled Plexi For Control Panel Option:
This kit is available to order with or without a pre-drilled plexi for the control panel. The clear plexi is a good option to choose, when you intend to put artwork underneath. This can be selected from the options above when ordering.

Removable Control Panel:
Introducing an exciting feature that has been added to this product - a removable control panel that allows for easy access to arcade parts for maintenance. This innovative addition is designed to enhance the user experience and simplify the maintenance process.

With the new removable control panel, you no longer need to struggle with complicated disassembly or risk damaging the delicate arcade parts. Simply detach the control panel from the main unit, and you'll have direct access to the internal components.

This feature is especially beneficial for arcade enthusiasts, technicians, and anyone who wants to ensure their arcade machine is always in optimal condition. Whether you need to clean, repair, or replace any of the arcade parts, the removable control panel makes it a breeze.

Here are some key advantages of the removable control panel:

  • Convenience: The control panel can be easily detached and reattached, allowing for quick and hassle-free maintenance.
  • Accessibility: With direct access to the arcade parts, you can easily reach and work on any component without the need for complex disassembly.
  • Time-saving: The removable control panel significantly reduces the time required for maintenance, enabling you to get back to enjoying your arcade machine sooner.
  • Durability: The control panel is designed to be sturdy and durable, ensuring it can withstand frequent removal and reattachment without compromising its functionality.

Whether you are a casual gamer or a dedicated arcade enthusiast, the new removable control panel will undoubtedly enhance your gaming experience and simplify the maintenance process. Say goodbye to complicated disassembly and hello to effortless access to arcade parts.
